Optimising cell culture outcomes and reproducibility
Creating successful cell cultures requires a CO2 Incubator that offers the highest levels of precision, security and ease of use.
Catalogue No.
Supplier
|
Catalogue No.
Optimising cell culture outcomes and reproducibility
Creating successful cell cultures requires a CO2 Incubator that offers the highest levels of precision, security and ease of use.
Optimising cell culture outcomes and reproducibility
Creating successful cell cultures requires a CO2 Incubator that offers the highest levels of precision, security and ease of use.
| External Dimensions (W x D x H) | 770 x 730 x 905 mm |
|---|---|
| Internal Dimensions (W x D x H) | 643 x 523 x 700 mm |
| Volume | 230 liters |
| Net Weight | 90 kg |
| Temperature Control Range & Fluctuation | AT +5 ~ +50, ±0.1 °C |
| Temperature Uniformity | ±0.25 °C |
| CO2 Control Range & Fluctuation | 0 ~ 20, ±0.15 % |
| O2 Control Range & Fluctuation | – |
| Humidity Level & Fluctuation | 95, ±5 %RH |
| Sterilisation Method | H2O2 Decontamination |
| Temperature Sensor | Thermistor |
| CO2 Sensor | Dual IR |
| O2 Sensor | – |
| Display | |
| Exterior Material | Painted Steel (rear cover not painted) |
| Interior Material | Stainless Steel Copper-Enriched Alloy |
| Insulation Material | Styrene AcryloNitrile copolymer |
| Heating Method | Direct Heat & Air Jacket System |
| Outer Doors | 1 |
| Outer Door Lock | Optional |
| Field Reversible Door | Included |
| Inner Doors | 1 gastight – made of tempered glass |
| Shelves | |
| Shelf Dimensions (W x D x H) | 620 x 450 x 12 mm |
| Max. Load Per Shelf | 7 kg |
| Max. Shelf Capacity | 10 |
| Access Port | 2 |
| Access Port Position | Rear |
| Access Port Diameter | 30 |
| Power Failure | R |
| Out of Temperature Setting | V-B-R |
| High Temperature | V-B-R |
| Out of CO2 Setting | V-B-R |
| Out of O2 Setting | – |
| Door Open | V-B |
| Power Supply | Local |
| Frequency | Local |
| Noise Level | 25 dB |
