ExPERT DTx™
The Power of ExPERT Electroporation to Fuel Discovery
Customizable, high-viability electroporation in a 96-well format
- Streamline workflow optimization.
- Scale for discovery to manufacturing.
- Cost-effective screening.
- Optimize electroporation parameters.
- High cell viability.
Brand: MaxCyte
SKU: ExPERT DTx™
Categories:
Electroporation Technology, Electroporation
The ExPERT DTx is a modular system with 4 components:
- Electroporation Module I generates the energy for electroporation
- DTx Processing Assembly Module (PAM) accommodates and delivers the charge to the Processing Assembly (PA)
- Electroporation Module Software – controls and monitors the DTx PAM
- DTx Designer software enables users to design an experiment remotely and upload it to the Electroporation Module I
- Integrated 10” touch-screen – Easily operate with just the touch of a finger
- Network capable – Generate and save run reports automatically onto a shared local drive
- Precision protocol control – intuitive slider adjustment to fine-tune electroporation
- Independent strip control – maximizes experimental flexibility and minimizes waste
- Compact footprint – a modern aesthetic for any high-tech lab space
| Item | Specifications |
| DTx Electroporation Module Dimensions | 19.6” (498 mm) X 12.6” (320 mm) X 10.7” (273 mm) |
| DTx Processing Assembly Module Dimensions | 9.9” (252 mm) X 11.1” (282 mm) X 4.4” (111 mm) |
| DTx Instrument Weight (EP Module + PA Module) | 47 lbs (21 kg) |
| DTx Input Power | 100-240 VAC, 50-60 Hz, 240 W |
| Fuse Requirements | 2 X 4 A Slow Blow, 250 V, 5 X 20 mm |
| Operating Humidity | 80% max (non-condensing) |
| Operating Temperature | 59°F – 86°F | 15°C – 30°C |
| Storage Temperature | 32°F – 113°F | 0°C – 45°C |
| Modes of Operation | Static |
| Process Volumes | 20 μL – 50 μL |
| Ports Available | 3 USB / 1 Ethernet |
- Service and Support
- Full installation and training by MaxCyte Field Applications Scientists
- Bi-annual system calibration, and preventative maintenance
- 24/7 remote support and global on-site assistance
- Consultation support for scaling to GMP
