Flow Electroporation processing assemblies for research applications in large-volume scales

Large-scale RUO Processing Assemblies

Flow Electroporation processing assemblies for research applications in large-volume scales.

Research Use Only (RUO) Flow Electroporation Processing Assemblies enable the discovery and development of applications at large scales. These flow electroporation consumables are made from high-grade, inert materials to protect precious cells. They include additional design features for easy sample loading and recovery and closed process adaptability.

R-20K™

• Maximum cell recovery at all volumes
• Bioweld compatible
• Designed for high-energy transfection

Configuration: Closed system, PVC bags and tubing with luer locking syringe ports
Cell Number: 2.5×10⁸ – 4×10⁹
Volume Range: 5 – 20 mL
Application: Research Use Only
Catalog: ER020M1-01
Compatible with: STx™

Graph Details: FITC Dextran (500 µg/mL) was electroporated into K562 cells (5×107 cells/ ml) using the CL-2 and R-20K processing assemblies. The final working volume in each device was 20 mL. Cells were counted after electroporation to determine viability.
