Robust design for safest storage of whole blood
The MBR-1405GR Blood Bank Refrigerator is designed to is designed to store 720 pcs of 450ml blood bags by the reliable temperature control utilizing PHCbi original technology.
Catalogue No.
Supplier
|
Catalogue No.
Robust design for safest storage of whole blood
The MBR-1405GR Blood Bank Refrigerator is designed to is designed to store 720 pcs of 450ml blood bags by the reliable temperature control utilizing PHCbi original technology.
Robust design for safest storage of whole blood
The MBR-1405GR Blood Bank Refrigerator is designed to is designed to store 720 pcs of 450ml blood bags by the reliable temperature control utilizing PHCbi original technology.
| External Dimensions (W x D x H) | 1440 x 830 x 1950 mm |
|---|---|
| Internal Dimensions (W x D x H) | 1320 x 697 x 1500 mm |
| Volume | 1301 litres |
| Net Weight | 315 kg |
| Capacity | 720 bags (450ml) |
| Temperature Setting Range | 4 °C +/-1.5 °C (AT 35°C) |
| Controller | Microprocessor |
| Display | Digital LED |
| Temperature Recorder | MTR-G04 (Included) |
| Temperature Sensor | 2 bottles with thermistor sensor |
| Exterior Material | Baked-on acrylic finish galvanised steel |
| Interior Material | Baked-on acrylic finish galvanised steel |
| Outer Doors | Insulated steel frame with double-layer glass windows |
| Outer Door Lock | 2 |
| Inner Doors | 6 Acrylic |
| Shelves | 12 coated hard steel wire shelves |
| Max. Load – Per Shelf/Drawer | 40 kg |
| Max. Load – Total | – |
| Access Port | 2 |
| Access Port Position | left and right hand side |
| Access Port Diameter | 30 |
| Casters | 4 |
| Interior Light | – |
| Power Failure | Y |
| High Temperature | Y |
| Low Temperature | Y |
| Door Open | Y |
| Power Supply | Local |
| Noise Level | – |
