Natural refrigerants and inverter technology
Naturally ocurring hydrocarbon (HC) refrigerants have minimal effect on the environment and are compliant with environmental legislation for climate control. Combined with inverter technology, these refrigerants also provide more efficient cooling without compromising cooling performance, ambient tolerance, and recovery speeds following door openings.
Natural refrigerants and inverter technology
Naturally ocurring hydrocarbon (HC) refrigerants have minimal effect on the environment and are compliant with environmental legislation for climate control. Combined with inverter technology, these refrigerants also provide more efficient cooling without compromising cooling performance, ambient tolerance, and recovery speeds following door openings.
| External Dimensions (W x D x H) | 790 x 882 x 1993 mm |
|---|---|
| Internal Dimensions (W x D x H) | 630 x 600 x 1400 mm |
| Volume | 528 litres |
| Net Weight | 241 kg |
| Capacity (2″ Boxes in Stainless Steel Racks) | 384 (2” boxes) |
| Cooling Performance | -86 to -40 °C |
| Temperature Setting Range | -90 to -40 °C |
| Temperature Control Range | -86 to -40 °C |
| Controller | Microcomputer control system |
| Display | LCD Digital display |
| Temperature Sensor | Platinum resistance (Pt 1,000 Ω) |
| Refrigeration System | Cascade |
| Compressors | 2 x 750 W |
| Refrigerant | HC |
| Insulation Material | Rigid polyurethane foamed-in place + Vacuum insulation panel |
| Exterior Material | Painted Steel |
| Interior Material | Painted Steel |
| Outer Doors/Lid | 1 |
| Outer Door Lock | Y |
| Inner Doors/Lid | 2 |
| Shelves | 3 |
| Max. Load – Per Shelf | 50 kg |
| Vacuum Release Port | 1 (automatic) |
| Access Port | 3 |
| Access Port Position | 3 (Black x 1, Bottom x 2) |
| Access Port Diameter | 17 |
| Casters | 4 (2 leveling feet) |
| Power Failure | V-B-M-R |
| High Temperature | V-B-M-R |
| Low Temperature | V-B-M-R |
| Filter | V-M |
| Door Open | V-B-M |
| Power Supply | Local |
| Frequency | Local |
| Noise Level | 52 dB [A] |
| Small Inner Door Kit set of 5 | MDF-5ID5-PW |
|---|---|
| Small Inner Door Kit set of 4 | MDF-5ID4-PW |
| Liquid CO2 back-up | MDF-UB9-PW |
| Inventory rack | IR-224U-PW, IR-316U-PW |
| Temperature recorders | |
| – Circular type | MTR-G85C-PE/MTR-G85A-PA – Chart paper: RP-G85-PW – Ink pen: PG-R-PW |
| – Continuous strip type | MTR-85H-PW – Chart paper: RP-85-PW – Ink pen: DF-38FP-PW – Recorder housing: MDF-S3085-PW |
| Recorder sensor cover | MTR-DU700SF-PW |
